Prepared for any contingency

Reliable, safe and durable, Avail Emergency Mobile Substations are a critical component to effective power recovery. Avail delivers a range of convenient solutions – all designed to restore or deliver power wherever you need it and as fast as you need it. Our trailer, skid and platform mounted Medium Voltage Switchgear can be designed to fit your needs, including:

• 5kV-38kV metal-clad switchgear
• 5kV-38kV Metal-Enclosed Interrupter (MEI) switchgear
• 5kV, 250MVA / 15kV 750MVA multi-rated switchgear
• Tamper-resistant M/C or MEI switchgear (IEEE C57.12.28)

Recently, Congress found that the storage of strategically located spare large power transformers and emergency mobile substations will reduce the vulnerability of the United States to multiple risks facing electric grid reliability, including physical attack, cyber attack, electromagnetic pulse, geomagnetic disturbances, severe weather, and seismic events. As a result, H.R. 22, the “Fixing America’s Surface Transportation Act” (FAST Act), includes several measures aimed at firming the U.S. electric grid against a variety of attacks and outages. The legislation was signed into law in December 2015, and is intended to develop a strategic reserve of transmission equipment, including transformers and Emergency Mobile Substations. To assist with compliance of this important piece of legislation, Avail is proud to offer Emergency Mobile Substations that are available fully assembled and permanently mounted on a trailer that is capable of highway travel and meets relevant Department of Transportation regulations and; Is intended for express deployment and capable of being rapidly placed into service.

Emergency and non-emergency solutions

Avail Emergency Mobile Substations and Portable Substations are invaluable when unexpected outages occur, and they also provide a wide range of applications and benefits that extend beyond unexpected outages:

• Small footprint
• Minimizes site preparation
• Switchgear to help extend transformer life
• Replace 5KV 26” air magnetic breakers with vacuum
• Tamper-resistant options
• With or without transformers

Contact Avail today to discuss your needs for Emergency Mobile Substations.

Protecting people and equipment through a commitment to safety that sets the industry standard

For over 50 years, Avail has been at the forefront of safety with innovative switchgear development. Offering an industry-leading, low-profile design that is Type 2C (2BC) compliant, Avail arc-resistant switchgear options meet or exceed IEEE, ANSI and NEMA requirements. Available in a wide range of ANSI ratings and configurations, our switchgear features utility-grade, welded, metal-clad assembly for reliability, safety and long service life.

Rigorous testing to ensure superior operation

Avail arc-resistant switchgear is type-tested to C37.20.7 at a world-class facility to ensure that it is fully compliant. Testing has been completed and results reported by a trusted and certified third-party source, and are available for customer review upon request.

 Our standard delivers exceptional performance

• Our wide range of ANSI rating product availability include:
  • Voltages: 5kV and 15kV
  • Continuous currents up to 3000A
  • Interrupting rating up to 40kA
• Patented nine-point visible door latch with visual confirmation of proper latching
• Lowest-profile plenum (under 20” high) fits in standard height enclosure and electrical rooms
• Double-walled switchgear construction
• Removable roof sections for easy replacement

Complete power protection, monitoring and control

For reliable electrical energy distribution, Avail’s PowerAisle II^® family of medium voltage switchgear has represented high quality, defined over 50 years of design and manufacturing experience. Rugged construction provides superior strength and durability, and all switchgear is designed to meet seismic and wind load requirements.

Avail offers a broad variety of metal-clad switchgear designs including:

• Voltages: 5kV to 38kV
• Metal-enclosed interrupter switchgear
• Dual rated switchgear
• Automatic transfer switchgear

Custom-built for optimal performance

Designed for future expansion and for use with any manufacturer’s circuit breakers, PowerAisle II switchgear features removable end walls as a standard feature, along with double-walled construction between switchgear compartments for added safety and durability. Fluidized bed epoxy bus insulation provides superior dielectric and thermal characteristics, and a fully undercoated base assembly protects against corrosion and ensures long life.

Additional features and benefits include:

• Completely wired and tested at the factory prior to shipment
• Externally removable air filter boxes with back-to-back louvers
• Installation capabilities compliant to IEC 61850 standards
• In-house lab and testing capabilities
