XML LED

Explosion proof lightweight, low-profile LED linear lighting for hazardous-rated environments

Order Form

Industry

Industrial | Oil Field | Wastewater Treatment

Type

LED

Luminaire

Explosion Proof | Hazardous-Rated | Industrial Lighting | Linear

Classification

The XML LED linear light delivers explosion-proof lighting for hazardous-rated locations with a lightweight, low-profile design. It features replaceable LED components, emergency battery backup, adjustable mounting brackets, and surge protection, ensuring reliable performance in demanding and challenging locations.

Standard Features:

Low-profile, lightweight design
Convenient wiring access through screw-cap cover with toolless, cage clamp terminal block
Self-contained emergency battery backup, no additional junction box required
Heavy-duty, 7/16″ thick die-cast safety cable attachment points
Replaceable LED circuit boards and drivers with quick disconnects
Adjustable mounting bracket with 90 degree range of motion and 13 locking positions (Not included. Must be ordered seperately.)

Additional Features:

Supplemental 10kV surge protection
Central safety cable attachment points for increased safety/reduced range of motion
Feed-through and pendant mount capable
Diffused lens option
Optional 0-10V dimming, range 10-100% (not available on EXML models or when EM option is selected)
7-year warranty

Classifications:

Class I, Division 2, Groups C & D
Class II, Division 2, Groups C & D
ATEX/IEC/EX approvals
UL 1598A marine outside type
UL 1598 wet locations
UL 8750 LED safety
UL 844 hazardous locations
UL 924 emergency lighting
CSA C22.2 No. 250.0–08
CSA C22.2 No. 137–M1981
IP66
NEMA 4X, 7CD
Tested to LM79, LM80 standards
DLC Listed LED
Build America, Buy America Act (BABA) compliant
Buy American Act (BAA) compliant
Paint Spray Booth
Emergency Battery Backup
-40°C to 65°C ambient temperature

Standard Materials:

Body: A360 Aluminum (less than .4% copper content) with baked-on gray epoxy finish
Gaskets: One-piece neoprene
Lens: Tempered glass
Hardware: Stainless steel

Contact Us

Request More Information

"*" indicates required fields

URL

This field is for validation purposes and should be left unchanged.

Company Name*

Name*

First Last

Email*

Phone

Address

Street Address Address Line 2 City County / State / Region ZIP / Postal Code Country

Interest

RIG-A-Lite

WSI South America

Other

RIG-A-LITE Project Type

WSI Project Type

File

If you would like to provide more details, upload a file

Max. file size: 100 MB.

How did you hear about us?

Comment

CAPTCHA

Product Details



View Dimensions



Lumens: 3,806-12,253



Approximate Shipping Weight: 26.5-36 lbs^*

*Mounting and options may increase weight. See Specifications download for details.
