Hazardous Locations & Lighting Fundamentals
Quick reference for hazardous location lighting classes, divisions, and groups.
AFL
Hazardous-rated HID flood lighting for challenging environments
Industry
Industrial | Marine | Oil Field
Type
HID
Luminaire
Flood | Hazardous-Rated | Industrial Lighting
Classification
The AFL Flood Light is a robust, hazardous-rated flood light designed for challenging locations including marine environments. With advanced photometric performance and durable construction, it ensures reliable operation under extreme conditions, making it ideal for industrial and hazardous area applications.
Standard Features:
- Precision-formed specular reflector for optimum photometric and lighting performance
- Hinged copper-free, cast-aluminum lens frame with stainless steel slotted hex head captive screws
- Marine-grade exposed hardware
- One-piece, copper-free, cast-aluminum lamp and ballast housing with baked-on bronze polyester powder-coat finish
- Thermal, shock, heat and impact-resistant tempered clear glass lens
- Weather-resistant high-temperature silicone or neoprene lens and lens door gasket
Additional Features:
- Eye bolt option (for safety cable)
- Mounting yoke
Classifications:
- Class I, Division 2, Groups A, B, C & D
- Zone 2, Groups IIA, IIB & IIC
- UL 1598A marine outside type
- UL 844 hazardous locations
- cUL
- Build America, Buy America Act (BABA) compliant
- Buy American Act (BAA) compliant
- 55°C ambient temperature
Standard Materials:
- Body: copper-free cast aluminum
- Gasket: silicone
- Lens: impact-resistant glass
- Hardware: marine-grade stainless steel
