This product is available for QuickShip Ordering (U.S. orders only)

SXPJ LED

Explosion proof LED area lighting with field-replaceable components for demanding high-risk environments

Industry

Industrial | Marine | Oil Field | Wastewater Treatment

Type

LED

Luminaire

Area | Explosion Proof | Industrial Lighting

Classification

The SXPJ LED explosion-proof area light provides reliable, high-performance lighting with easily field-replaceable components and quick disconnects. Its robust construction and advanced safety features ensure long-lasting, dependable illumination in demanding high-risk applications.

Standard Features:

Single-pin quick disconnect mount with double acme thread
Component access via single set screw
Field-replaceable LED circuit boards and drivers with quick disconnects
Wireless electromechanical terminal block

Additional Features:

Supplemental 10kV surge protection
Standard, angle and high-bay reflector options available
Pendant, ceiling, wall, stanchion and trunnion-mounting options
Optional stainless steel guard
5-year warranty

Classifications:

Class I, Division 1, Groups C & D
Class II, Division 1, Groups E, F & G
Class III
Zone 1, Groups IIA & IIB
ATEX/IEC/EX approvals
UL 844 hazardous locations
UL 1598 wet locations
UL 1598A marine outside type
UL 8750 LED safety
cUL
IP66
NEMA 4X
Tested to LM79, LM80 standards
Build America, Buy America Act (BABA) compliant
Buy American Act (BAA) compliant
2.34 spacing criteria-compliant
55°C maximum ambient temperature

Standard Materials:

Body: A360 aluminum (less than .4% copper content) with baked-on gray epoxy finish
Gaskets: one-piece silicone
Lens: borosilicate glass
Hardware: stainless steel
