FPF
NSF-certified fluorescent linear lighting with emergency backup for food processing and harsh-rated locations
FPF LED
NSF-certified LED linear lighting for high-pressure cleaning in wet, harsh-rated locations
Industry
Food Processing | General Purpose
Type
LED
Luminaire
Heavy Duty Harsh-Rated | Linear
Classification
The FPF LED linear light offers NSF-certified, debris-shedding lighting with a patented design ideal for harsh-rated and sanitary environments. Durable and easy to maintain, this heavy duty, non-metallic fixture is specifically engineered for high-pressure cleaning and wet locations.
Standard Features:
- Patented liquid- and debris-shedding design
- Patented dual gasket seals
- 3′ #16 AWG 3 conductor cable and cord grip
- Single-bolt access to components
- Field-replaceable LED circuit boards and drivers with quick disconnects
-
Industry leading watershed design
-
Impact resistant DR acrylic housing
Additional Features:
- Diffused lens
- Heavy-duty extruded aluminum LED tray
- Optional emergency battery back-up with EM markings
- Optional stainless steel end caps
- Optional dimmable driver
-
Standard 10kV surge protection
-
Optional quick disconnect 3P plug and receptacle with 6’ cord
- 7-year warranty
Classifications:
- UL 1598 wet locations
- UL 8750 LED safety
- CSA C22.2 No. 250.0-08
- IP69K
- NEMA 4X
- NSF-certified food equipment
- Tested to LM79, LM80 standards
- DLC listed (on certain models)
- Build America, Buy America Act (BABA) compliant
- Buy American Act (BAA) compliant
- -20°C to 35°C ambient temperature
- 85 CRI option available
Standard Materials:
- Body/lens: DR acrylic
- LED tray: 6063-T5 aluminum
- Driver cover: 3105 H24 aluminum
- End caps: polycarbonate
- Gasket: silicone
- Diffuser: acrylic
- Hardware: stainless steel
Contact Us
Product Details
Lumens: 4,169-16,674
Approximate Shipping Weight: 10-30 lbs*
