EXA04 LED
EX-Series explosion-proof LED flood light for hazardous-rated locations
Industry
Industrial | Marine | Oil Field | Wastewater Treatment
Type
LED
Luminaire
EX-Series | Explosion Proof | Flood | Hazardous-Rated | Industrial Lighting
Classification
The EXA04 LED, part of the RIG-A-LITE EX-Series, delivers IECEx and ATEX-certified explosion-proof lighting for hazardous-rated environments. Built for installations in the Middle East, North Africa, Southeast Asia, and other regions requiring ATEX/IECEx certification, the EXA04 offers reliable flood lighting in demanding conditions.
Please note: Not for installations in North America.
Standard Features:
- Available in 150W, 200W, 240W
- Efficiency is up to 150 Lm/W
- 12 optical patterns available to accommodate a variety of applications
- Max operating temperature range: -40°C to 65°C
- Optional stainless steel guard and visor
- Adjustable bracket, mounting angle ± 90°
- Warm white/cool white color and colored R/G/B/Amber options
- Standard 10Kv surge protection
- 5-year warranty
Classifications:
- Class I, Division 2, Groups A, B, C & D
- Class II, Division 1, Groups E, F & G
- Class II, Division 2, Groups F & G
- Class III
- Class I, Zone 1, Groups IIC, IIB, IIA
- Zone 21, Zone 22
- IECEx approvals
• Ex nR IIC T6/T5 Gc
• Ex tb IIIC T80 C/T95 C Db IP66 - ATEX approvals
• II 3G Ex nR IIC T6/T5 Gc
• II 2D Ex tb IIIC T80 C/T95 C Db IP66 - UL 1598A marine outside type
- IP66
- IK08
